Bently Nevada 330903-00-02-05-12-05 NSv Proximity Probe
Experience exceptional precision with the Bently Nevada 3300 NSv Proximity Probe, engineered for critical vibration monitoring in demanding industrial applications. This certified solution delivers reliable performance in hazardous environments and process compressor systems.
📋 Product Configuration & Identification
- Manufacturer: Bently Nevada
- Product Line: 3300 NSv Proximity Probes
- Full Part Number: 330903-00-02-05-12-05
- Mounting Thread: M8X1 without armor protection
- Unthreaded Section: 00 mm (-00- option)
- Case Dimensions: 20 mm length (-02- option)
- Cable Specification: 0.5 meter length (-05- option)
- Connection Interface: Miniature coaxial ClickLoc with FluidLoc cable (-12-)
- Certification Status: Multiple agency approvals (-05- option)
- Product Condition: New & Original in factory packaging
🎯 Measurement Performance Characteristics
- Measurement Range: 1.5 mm (60 mils) linear range
- Initial Offset: Begins at 0.25 mm from target surface
- Optimal Gap Setting: 1.0 mm (40 mils) recommended
- Sensitivity Factor: 7.87 V/mm (200 mV/mil)
- Linearity Accuracy: Better than ±0.06 mm (±2.3 mils)
- Frequency Response: 0 to 10 kHz (±3 dB typical)
- Target Requirements: Minimum 8.9 mm, Recommended 13 mm diameter
🛡️ Environmental & Safety Ratings
- Operating Temperature: -52°C to +177°C (-62°F to +351°F)
- Storage Temperature: -52°C to +177°C (-62°F to +351°F)
- Pressure Sealing: Viton O-ring differential pressure seal
- Safety Certifications: Multiple agency approvals included
- Chemical Resistance: Enhanced compared to previous models
- Ingress Protection: Designed for industrial environments
🔧 Mechanical Specifications
- Probe Tip: Polyphenylene Sulfide (PPS) material
- Case Material: AISI 304 Stainless Steel construction
- Cable Insulation: Fluoroethylene Propylene (FEP) rated
- Bend Radius: Minimum 25.4 mm (1.0 inch)
- Mounting Torque: Finger tight (Maximum 0.56 N•m)
- Thread Engagement: Maximum 12 mm for M8x1 thread
- Connector Torque: 5.1-7.3 N•m recommended range
