Description
Overview
The 330101 – 00 – 59 – 15 – 02 – CN is a 3300 XL 8 – mm probe by Bently Nevada, crafted in the U.S.A. It offers the option of a Certificate of Origin. This probe, featuring a 3/8 – 24 UNF thread and no armor, showcases advanced design elements such as patented TipLoc and CableLoc. An optional FluidLoc cable can be ordered to prevent liquid leakage.
Technical Specification
- Brand: Bently Nevada
- Model: 330101 – 00 – 59 – 15 – 02 – CN
- Suffix Meaning:
- CN: Country Specific Approval
- 02: Miniature coaxial ClickLoc connector with standard cable
- Dimensions:
- Unthreaded length: 0.0 in
- Overall case length: 5.9 in
- Total length: 1.5 m (4.9 ft)
- Electrical:
- For 1.5 – m probe, RPROBE: 7.73 ± 0.50 Ω
- Extension cable capacitance: 69.9 pF/m
- Performance:
- Linear range: 2 mm (80 mils), starting about 0.25 mm from target
- Radial vibration gap: -9 Vdc (1.27 mm)
- Incremental Scale Factor (ISF):
- Standard 5 or 1 – m system: 7.87 V/mm (200 mV/mil) ± 5%
- Standard 9 – m system: 7.87 V/mm (200 mV/mil) ± 6.5%
- ETR (5 & 9 – m systems): 7.87 V/mm (200 mV/mil) ± 6.5%
- Deviation from best – fit straight line (DSL):
- Standard 5 or 1 – m system: < ±0.025 mm (±1 mil)
