Description
Bently Nevada 3300 NSv Proximity Probe: Advanced Machinery Protection
The 330905-00-13-10-02-00 offers superior vibration monitoring. This M10X1 thread probe ensures reliable performance. It features enhanced chemical resistance for tough environments.
Product Code Breakdown
- Series: 3300 NSv Proximity Probe
- Thread Type: M10X1
- Unthreaded Length: 00 (0 mm)
- Case Length: 13 (130 mm)
- Cable Length: 10 (1.0 meter)
- Connector: 02 (Miniature ClickLoc)
- Approval: 00 (Not required)
Key Technical Specifications
- Manufacturer: Bently Nevada
- Part Number: 330905-00-13-10-02-00
- Linear Range: 1.5 mm (60 mils)
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Frequency Response: 0 to 10 kHz
- DC Resistance: 4.2 ± 0.5 ohms
- Minimum Target Size: 8.9 mm diameter
- Recommended Target: 13 mm diameter
- Operating Temperature: -52°C to +177°C
- Case Material: AISI 304 Stainless Steel
- Tip Material: PPS Plastic
- Maximum Torque: 0.56 N•m (5 in•lb)
- Cable Type: 75 Ω coaxial FEP insulated
Technical FAQs
- What is the maximum field wiring length?
Up to 305 meters between probe and monitor. - How does this probe compare to 3000-series 190 probes?
It offers superior side-view characteristics at same gap distances. - What torque should be applied during installation?
Finger tight with maximum of 0.56 N•m (5 in•lb). - Can it measure axial position on small shafts?
Yes, but scale factor may change for shafts under 13 mm diameter. - What is the minimum bend radius for the cable?
25.4 mm (1.0 inch) with or without armor.
