Bently Nevada 330904-00-10-05-02-00: Armored Precision for Demanding Applications
Engineered for challenging industrial environments, the Bently Nevada 3300 NSv proximity probe with stainless steel armor offers superior durability. This specific model, 330904-00-10-05-02-00, provides exceptional mechanical protection without compromising measurement accuracy. Its enhanced construction makes it perfect for installations where cable damage is a concern. We ensure quick delivery worldwide via FedEx, UPS, or DHL.
Model Configuration: Decoding 330904-00-10-05-02-00
Every segment of the part number defines a specific feature of your probe. This detailed breakdown ensures you get the exact specifications required for your application.
- 330904 → Probe Series: 3300 NSv with M8x1 thread and stainless steel armor
- 00 → Unthreaded Length: 00 millimeters
- 10 → Overall Case Length: 100 millimeters
- 05 → Total Cable Length: 0.5 meters (20 inches)
- 02 → Connector: Miniature coaxial ClickLoc, standard cable
- 00 → Agency Approvals: Not required for this configuration
Core Technical Specifications
The 3300 NSv probe delivers consistent and reliable performance for machinery protection systems.
- Manufacturer & Brand: Bently Nevada
- Complete Model: 330904-00-10-05-02-00
- Electrical Resistance: 4.0 ± 0.5 ohms (for the 0.5m length)
- Measurement Range: 1.5 mm (60 mils) linear range
- Sensitivity (Scale Factor): 7.87 V/mm (200 mV/mil)
- Linearity (Deviation from DSL): Better than ±0.06 mm (±2.3 mils)
- Frequency Response: 0 to 10 kHz (+0, -3 dB typical)
- Optimal Gap Setting: 1.0 mm (40 mils) from the target
- Minimum Target Diameter: 13 mm (0.5 inches) recommended
Enhanced Product Features & Environmental Ratings
This probe is built to perform reliably under extreme operating conditions.
- Armor Material: AISI 304 Stainless Steel for maximum cable protection
- Probe Tip: Chemically resistant Polyphenylene Sulfide (PPS)
- Temperature Range: Operates from -52°C to +177°C (-62°F to +351°F)
- Cable Insulation: Fluoroethylene Propylene (FEP) for durability
- Cable Impedance: 75 Ohm coaxial design
- Minimum Bend Radius: 25.4 mm (1.0 inch) to prevent damage
- Sealing: Viton O-ring for differential pressure sealing
Installation & Mechanical Specifications
Follow these guidelines for a correct and safe installation process.
- Installation Torque: Hand tight plus 5.1 N•m (45 in•lb) maximum
- Absolute Maximum Torque: Never exceed 7.3 N•m (65 in•lb)
- Thread Engagement: Maximum 12 mm for M8x1 thread
- Field Wiring: Use shielded triad cable up to 305 meters (1000 feet)
- Extension Cable Resistance: Center conductor: 0.220 Ω/m; Shield: 0.066 Ω/m
Package Contents
You will receive the following items in your shipment.
- One (1) Bently Nevada 3300 NSv Proximity Probe, 330904-00-10-05-02-00
- One (1) Miniature coaxial ClickLoc connector attached
- All components are new and original, packed in factory sealing
