Description
Bently Nevada 330904-00-06-05-02-05: Armored for Demanding Environments
The 3300 NSv proximity probe with stainless steel armor offers superior protection in harsh industrial settings. This 330904-00-06-05-02-05 model provides excellent chemical resistance and mechanical durability. It ensures reliable machinery monitoring for critical applications like compressors and turbines. The probe comes new and original directly from factory sealed packaging.
Product Identification & Configuration
This specific model features a detailed configuration code for precise identification.
- Manufacturer: Bently Nevada
- Core Model: 3300 NSv Proximity Probes
- Full Part Number: 330904-00-06-05-02-05
Detailed Configuration Tree
Understand every feature of your probe with this detailed breakdown.
- → 330904: Base Model (3300 NSv Probe, M8x1 thread, WITH armor)
- → -00-: Unthreaded Length Option: 00 mm
- → -06-: Overall Case Length Option: 60 mm
- → 05: Total Length Option: 0.5 meter (20 inches)
- → 02: Connector/Cable: Miniature coaxial ClickLoc, standard cable
- → 05: Agency Approvals: Multiple Approvals
Core Performance Specifications
This probe delivers accurate and consistent data for predictive maintenance programs.
- Linear Measurement Range: 1.5 mm (60 mils) from 0.25 to 1.75 mm from target.
- System Sensitivity (Scale Factor): 7.87 V/mm (200 mV/mil).
- Linearity Error (DSL): Less than ±0.06 mm (±2.3 mils) across the full range.
- Frequency Response Bandwidth: 0 to 10 kHz, perfect for high-speed machinery.
- Electrical Resistance (0.5m length): 4.0 ± 0.5 ohms.
- Optimal Gap Setting: 1.0 mm (40 mils) from the target surface.
Robust Construction & Durability
Built to withstand extreme conditions found in industrial plants worldwide.
- Armor Protection: Full AISI 304 stainless steel armor for mechanical safety.
- Probe Tip Material: Polyphenylene sulfide (PPS) for excellent chemical resistance.
- Temperature Tolerance: Operates from -52°C to +177°C (-62°F to +351°F).
- Cable Insulation: 75-ohm coaxial with fluoroethylene propylene (FEP).
- Sealing: Viton O-ring seals the probe tip against differential pressure.
- Minimum Bend Radius: 25.4 mm (1.0 inch) to prevent cable damage.
Installation & Integration Guide
Follow these guidelines for a successful and long-lasting installation.
- Target Requirements: Minimum 8.9 mm diameter, recommended 13 mm or larger.
- Mounting Torque: Hand tight or up to 5.1 N•m (45 in•lb) maximum.
- Absolute Maximum Torque: Never exceed 7.3 N•m (65 in•lb).
- Thread Engagement: Engage M8x1 threads a maximum of 12 mm.
- Field Wiring: Use shielded triad cable up to 305 meters (1000 feet).
Ordering & Delivery Details
We provide fast global shipping and guaranteed original products.
- Product Condition: 100% New & Original, in factory packaging.
- Shipping Methods: Fast worldwide delivery via FedEx, UPS, and DHL.
- Package Includes: One Bently Nevada 3300 NSv Probe, model 330904-00-06-05-02-05.
For technical specifications or volume pricing, contact sales@plc-pioneer.com or +86 18150899927.
