Description
Bently Nevada 3300 NSv Proximity Probe – Advanced Vibration Monitoring Solution
Complete Product Identification
- Manufacturer: Bently Nevada
- Series: 3300 NSv Proximity Probes
- Full Part Number: 330903-00-02-10-11-05
- Condition: New & Original in Factory Packaging
Model Suffix Detailed Breakdown
- Base Model: 330903 (3300 NSv Probe, M8X1 thread, without armor)
- Unthreaded Length: -00- (00 mm)
- Case Length: -02- (20 mm overall case length)
- Cable Length: -10- (1.0 meter/39 inches total length)
- Connector Type: -11- (Miniature coaxial ClickLoc with protector, FluidLoc cable)
- Certification: -05- (Multiple agency approvals)
Technical Specifications
- Measurement Range: 1.5 mm (60 mils) linear range from 0.25 to 1.75 mm
- Frequency Response: 0 to 10 kHz (+0/-3 dB) with 305m field wiring
- Sensitivity: 7.87 V/mm (200 mV/mil) ±12.5%/-20% including interchangeability
- Linearity: ±0.06 mm (±2.3 mils) deviation from best fit straight line
- Probe Resistance: 4.2 ± 0.5 ohms at 1.0 meter length
- Temperature Range: -52°C to +177°C operating and storage
- Target Size: Minimum 8.9 mm, recommended 13 mm diameter
- Cable Specifications: 75 Ω coaxial with FEP insulation
Frequently Asked Questions
- Q: Is the 3300 NSv probe compatible with existing monitoring systems?
A: Yes, it maintains full compatibility with previous 3300 RAM probe systems - Q: What makes this probe suitable for chemical environments?
A: The PPS tip material and enhanced construction provide superior chemical resistance - Q: What is the maximum cable length supported?
A: The system supports up to 305 meters of field wiring between probe and monitor - Q: How does this probe improve upon previous models?
A: It offers better side-view characteristics and increased environmental resistance
