Description
Bently Nevada 3300 NSv Proximity Probe – Reliable Vibration Monitoring
The Bently Nevada 330905-05-25-10-02-00 delivers high-performance sensing for industrial vibration measurement. It features excellent chemical resistance and improved side-view characteristics. This makes it perfect for demanding applications like process compressors. The 3300 NSv probe works seamlessly with older 3300 RAM system components.
Complete Model Suffix Information
- 330905: Base Model Number
- -05: 50 mm Unthreaded Length
- -13: 130 mm Overall Case Length
- -10: 1.0 Meter Cable Length
- -12: Miniature Coaxial ClickLoc Connector, FluidLoc Cable
- -00: No Agency Approval Required
Technical Specifications
- Brand: Bently Nevada
- Model: 330905-05-13-10-12-00
- Linear Range: 0.25 to 1.75 mm (10 to 70 mils)
- Recommended Gap Setting: 1.0 mm (40 mils)
- Sensitivity (ISF): 7.87 V/mm (200 mV/mil) ±12.5%/-20%
- Linearity (DSL): Better than ±0.06 mm (±2.3 mils)
- Frequency Response: 0 to 10 kHz (±3 dB with 305m wiring)
- Temperature Range: -52°C to +177°C (-62°F to +351°F)
- Probe Resistance: 4.2 ± 0.5 Ω for 1.0m cable
- Cable Capacitance: 69.9 pF/m typical
- Minimum Target Size: 8.9 mm (0.35 in) diameter
Frequently Asked Questions
- Is the 3300 NSv compatible with existing 3300 RAM systems?
Yes, it offers full mechanical and electrical compatibility. - What is the maximum cable length supported?
Up to 305 meters (1000 feet) of field wiring. - Can this probe handle high-pressure environments?
It features a Viton O-ring seal but requires custom testing for pressure applications. - What is the typical output voltage range?
Approximately -1 to -13 Vdc over the linear measurement range.
