Description
Bently Nevada 3300 NSv Proximity Probe – 330905-05-10-10-01-05
Experience superior machinery protection with the Bently Nevada 3300 NSv Proximity Probe. This industrial-grade sensor delivers exceptional accuracy for vibration and position monitoring in demanding applications. The 330905-05-10-10-01-05 model features a 100mm case length with connector protector, making it ideal for installations requiring extended reach and additional connector protection.
Model Number Configuration
- Base Model: 330905 (3300 NSv Probe, M10x1 Thread)
- Configuration Breakdown:
- -05- → Unthreaded Length: 50 mm
- -10- → Case Length: 100 mm
- -10- → Cable Length: 1.0 meter (39 inches)
- -01- → Connector: Miniature ClickLoc with Protector
- -05 → Approvals: Multiple Agency Certifications
Technical Performance Specifications
- Measurement Range: 1.5 mm (60 mils) linear range
- Optimal Gap Setting: 1.0 mm (40 mils) from target surface
- Sensitivity: 7.87 V/mm (200 mV/mil) incremental scale factor
- Frequency Response: 0 to 10 kHz (±3 dB typical)
- Linearity Error: < ±0.06 mm (±2.3 mils) deviation
- Temperature Range: -52°C to +177°C operational
- Electrical Resistance: 4.2 Ω ± 0.5 Ω (1 meter cable)
- Case Material: AISI 304 stainless steel construction
- Tip Material: Chemical-resistant PPS (Polyphenylene Sulfide)
- Sealing: Viton O-ring for pressure differential protection
Installation & Mounting Specifications
- Thread Specification: M10 x 1.0 metric thread
- Maximum Thread Engagement: 15 mm depth
- Installation Torque: Finger tight plus ¼ turn maximum
- Maximum Torque: 0.56 N•m (5 in-lb) absolute limit
- Connector Torque: 7.5 N•m (66 in-lb) recommended
- Minimum Bend Radius: 25.4 mm (1.0 inch) for cable protection
Electrical & Wiring Specifications
- Cable Type: 75Ω coaxial with FEP insulation
- Cable Capacitance: 69.9 pF/meter typical value
- Field Wiring: Shielded triad cable recommended
- Wire Gauge: 0.25-0.75 mm² (18-23 AWG) with ferrules
- Maximum Distance: 305 meters to 3300 XL NSv Proximitor
- Extension Cable Resistance: 0.220 Ω/m center conductor
Packaging & Shipping Information
- Product Condition: New & original in factory packaging
- Package Contents: 1 × 3300 NSv Probe with connector protector
- Shipping Carriers: FedEx, UPS, DHL international services
- Warranty Protection: 12-month warranty included
