Description
Bently Nevada 3300 NSv Standard Length Proximity Probe
The Bently Nevada 3300 NSv Proximity Probe (Part Number: 330905-05-08-10-02-00) features a standard 80mm case length with 1.0 meter integrated cable. This industrial vibration sensor provides reliable machinery protection with M10x1 threading and standard ClickLoc connector. Perfect for most rotating equipment monitoring applications.
Product Identification
- Manufacturer: Bently Nevada
- Product Line: 3300 NSv Proximity Probes
- Complete Part Number: 330905-05-08-10-02-00
- Condition: New & Original Factory Packaging
- Warranty: 12 Months Manufacturer Coverage
Performance Specifications
- Measurement Range: 1.5mm (60 mils) linear range
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linearity: Better than ±0.06mm (±2.3 mils)
- Frequency Response: 0-10 kHz (±3dB typical)
- Temperature Rating: -52°C to +177°C operational
- Electrical Resistance: 4.2±0.5Ω for 1.0m cable
- Target Size: Minimum 8.9mm, recommended 13mm
- Cable Resistance: Center conductor 0.220 Ω/m
- Cable Capacitance: 69.9 pF/m typical
Installation Specifications
- Recommended Torque: Finger tight installation
- Maximum Torque: 0.56 N·m (5 in·lb) limit
- Thread Engagement: Maximum 15mm depth
- Gap Setting: 1.0mm (40 mils) recommended
- Field Wiring: 0.2-1.5mm² shielded triad cable
- Maximum Distance: 305 meters to monitor
