Description
Bently Nevada 3300 NSv Proximity Probe – 330905-00-06-50-12-00
The Bently Nevada 330905-00-06-50-12-00 is a high-performance industrial proximity probe. It delivers reliable vibration and position monitoring for critical machinery. This new 3300 NSv model offers superior chemical resistance and performance.
Full Suffix Information
- Model: 330905
- Thread Type: M10X1 (Without Armor)
- Unthreaded Length: 00 (0 mm)
- Case Length: 06 (60 mm)
- Cable Length: 50 (5.0 meters / 16.4 ft)
- Connector Type: 12 (Miniature Coaxial ClickLoc, FluidLoc Cable)
- Agency Approval: 00 (Not Required)
Technical Specifications
- Brand: Bently Nevada
- Model: 330905-00-06-50-12-00
- Linear Range: 1.5 mm (60 mils)
- Recommended Gap Setting: 1.0 mm (40 mils)
- Incremental Scale Factor (Sensitivity): 7.87 V/mm (200 mV/mil)
- Frequency Response: 0–10 kHz (±3 dB typical)
- DC Resistance (5m cable): 5.3 Ω ± 0.7
- Operating Temperature: -52°C to +177°C (-62°F to +351°F)
- Probe Tip Material: Polyphenylene Sulfide (PPS)
- Case Material: AISI 304 Stainless Steel
- Minimum Target Size: 8.9 mm (0.35 in) diameter
Frequently Asked Questions
- Is this probe compatible with existing Bently Nevada systems?
Yes, it is mechanically and electrically compatible with previous 3300 RAM probes. - What is the maximum field wiring distance?
You can use up to 305 meters (1000 feet) between the probe and monitor. - Can this probe handle high-pressure environments?
The probe features a Viton O-ring seal but is not pressure-tested by default.
