Bently Nevada 330903-00-04-70-01-00 Extended Range Proximity Probe
The Bently Nevada 3300 NSv extended length proximity probe delivers exceptional performance for demanding applications. This specific configuration 330903-00-04-70-01-00 features a 7-meter cable with protective connector design. It offers superior sensing capabilities with extended reach for complex installation scenarios.
Product Configuration Matrix
- Series Identifier: 330903 (3300 NSv Probe, M8X1)
- Unthreaded Length: 00 (0 mm exposed length)
- Case Dimension: 04 (40 mm total case length)
- Cable Specification: 70 (7.0 meters / 23.0 feet)
- Connection System: 01 (ClickLoc with connector protector)
- Compliance Status: 00 (No agency approvals required)
Performance Excellence
- Extended Reach: 7.0 meter integrated cable length
- Electrical Characteristic: 5.9 ± 0.9 ohms resistance
- Measurement Range: 1.5 mm linear operating range
- Sensitivity: 7.87 V/mm (200 mV/mil) output
- Linearity: ±0.06 mm maximum deviation
- Bandwidth: 10 kHz frequency response
- Temperature Range: -52°C to +177°C operational
Installation Specifications
- Optimal Sensing Gap: 1.0 mm from target surface
- Target Requirements: Minimum 8.9mm diameter
- Mounting Torque: 5.1 N•m maximum recommended
- Connection Handling: 0.56 N•m connector torque limit
- Cable Management: 25.4 mm minimum bend radius
- System Integration: 305 meter maximum field wiring
- Thread Engagement: 12 mm maximum for M8x1 threads
Comparative Analysis
- Compared to 330903-00-05-50-11-05: Different case length and cable type
- Compared to 330903-00-02-05-01-05: Shorter cable length variant
Expert Technical Consultation
- What applications benefit from the 7-meter cable length?
This extended length is ideal for large machinery and complex installation layouts. - How does the connector protector enhance reliability?
It provides physical protection against impact and environmental damage. - Can this probe handle high-pressure environments?
The Viton O-ring provides effective sealing for differential pressure applications. - What maintenance advantages does this model offer?
Its robust design requires minimal maintenance while ensuring long service life. - How does the extended length affect signal quality?
The probe maintains excellent signal integrity across the entire 7-meter length.
