Bently Nevada 3300 NSv Proximity Probe – 330905-05-25-10-02-05
The Bently Nevada 330905-05-25-10-02-05 sets a new standard for precision vibration monitoring. This premium proximity probe delivers exceptional performance in demanding industrial environments. Engineers trust the 3300 NSv series for critical machinery protection applications.
Product Identification Breakdown
- Base Model: 330905 (M10X1 Thread, No Armor)
- Unthreaded Length: 05 (50 mm)
- Case Length: 25 (250 mm)
- Probe Cable: 10 (1.0 Meter/39 Inches)
- Connection System: 02 (Mini Coaxial ClickLoc, Standard Cable)
- Certification: 05 (Multiple Agency Approvals)
Enhanced Technical Specifications
- Measurement Range: 1.5 mm (60 mils) linear range
- Sensitivity: 7.87 V/mm (200 mV/mil) ±12.5%/-20%
- Linearity: ±0.06 mm (±2.3 mils) deviation from straight line
- Frequency Response: 0-10 kHz (±3 dB with 305m field wiring)
- DC Resistance: 4.2 Ω ± 0.5 (1.0 meter cable)
- Temperature Range: -52°C to +177°C (-62°F to +351°F)
- Minimum Target: 8.9 mm diameter (13 mm recommended)
- Cable Impedance: 75 Ohm coaxial with FEP insulation
- Extension Cable Resistance: 0.220 Ω/m center, 0.066 Ω/m shield
Packaging & Shipping Details
- Factory original packaging with protective materials
- Worldwide express shipping via FedEx, UPS, or DHL
- Package includes:
- One 3300 NSv proximity probe assembly
- Miniature coaxial ClickLoc connector
- Standard specification cable (1.0 meter length)
All Bently Nevada 330905 products include 12-month warranty and technical support. This probe meets the highest standards for industrial vibration monitoring and protection systems.
